| Basic Information | ||
| Processor | Intel Core i3-14100 (12M Cache, up to 4.7GHz) | |
| Motherboard | Intel B760 Chipset | |
| RAM | 8GB DDR5-5600MHz Two DDR5 UDIMM slots, dual-channel capable Up to 64GB DDR5-5600 | |
| Graphics Card | Integrated Intel UHD Graphics 730 | |
| Storage | 512GB M.2 2280 PCIe NVMe SSD | |
| Audio | High Definition (HD) Audio, Realtek® ALC623-CG codec | |
| Power Supply | 180W | |
| Operating System | Free DOS | |
| Security Management | Discrete TPM 2.0, TCG certified | |
| Others | Bays 1x 2.5" disk bay (optional) 1x 3.5" disk bay 1x slim ODD bay Expansion Slots One PCIe 3.0 x16, full-height, length ≤ 233.6mm, height ≤ 117.5mm One PCIe 3.0 x1, full-height, (length ≤ 185mm, height ≤ 100mm) or (length ≤ 118mm, height ≤ 110mm) Two M.2 slots (one for WLAN, one for SSD) Optical: DVD-ROM, SATA 1.5Gb/s, slim (9.0mm) | |
| Input Devices | ||
| Keyboard | USB Calliope Keyboard, Black, English | |
| Mouse | USB Calliope Mouse, Black | |
| External I/O Ports | Front Ports 1x USB-C (USB 5Gbps / USB 3.2 Gen 1), with data transfer and 15W charging 4x USB-A (USB 5Gbps / USB 3.2 Gen 1) 1x headphone / microphone combo jack (3.5mm) 1x microphone (3.5mm) Rear Ports 4x USB-A (Hi-Speed USB / USB 2.0), one supports Smart Power On 1x HDMI 2.1 TMDS 1x DisplayPort 1.4a (HBR2) 1x VGA 1x Ethernet (RJ-45) 1x line-out (3.5mm) Optional Rear Ports 1x parallel 2x serial 2x PS/2 | |
| Physical Details | ||
| Dimension | 240 x 395 x 530 mm (9.45 x 15.55 x 20.87 inches) | |
| Weight | Around 5.6 kg (12.35 lbs) | |
| Color | Luna grey (front bezel), raven black (chassis) | |
| Warranty Information | ||
| Warranty | 3 years Warranty | |
