| Main Feature | ||
| Capacity | 650VA | |
| Input Voltage | 230Vac |
|
| Output Voltage | 230 (+/-10%) | |
| Frequency (Battery Mode) | 50 Hz ±1 Hz |
|
| Battery | 12V Battery AC Voltage Regulation: 230+/-10%(Battery mode) Frequency Range: 50 Hz ±1 Hz(Battery mode) |
|
| Input Features | ||
| Frequency | 40 Hz (auto sensing)”}”>>40 Hz (auto sensing) |
|
| Voltage Range | 140 – 300 Vac |
|
| Output Features | ||
| Backup Time | Max. 12 Min(Standard) | |
| Voltage Range | 230 (+/-10%) | |
| Type of Wave | Simulated Sine Wave | |
| Transfer Time | Typical 4-8ms, 13ms max | |
| Physical Specification | ||
| Dimension | 301 x 101 x142.5 |
|
| Weight | Approx. 4.3 |
|
| Manufacture Warranty | ||
| Warranty | 1 Year Warranty Under the following conditions, the warranty would not be provided: • UPS burning due to thunder, abnormal overload, insect entrance and others. • If ambient temperature should not be maintained at 20 to 26 degrees Celsius with proper dehumidification. (24/7) • If the product is placed in a dusty and damp place. • In the absence of Generator connectivity Without proper battery charge, the warranty will be void. • Battery swelling and overcharging due to the wrong system voltage setting of the UPS. | |
